> >>Swivel coupling MF1/4 SW25 stainless steel
Swivel coupling MF1/4 SW25 View larger

Swivel coupling MF1/4 SW25 stainless steel

PA26.1200.20

New product

Swivel coupling MF1/4 SW25 stainless steel
Fittings G1/4 M cone 60 °
Swivel couplings SW25
Swivel joint with stainless steel ball bearing
Sturdy construction in nickel-plated brass and stainless steel
Compact dimensions, high performance
Provved oblique stainless steel balls
It can bear radial and axial loads

More details

70,00 € tax excl.

More info

Nominal pressure 250 bar - 25 MPa - 3650 psi
Pressure Permitted 280 bar - 28 MPa - 4050 psi
Nominal flow 40 l / min - 10.5 USGpm
Nominal temperature 120 ° C - 250 ° F
Maximum working temperature 90 ° C - 194 ° F
Maxi revolutions 30 rpm
Material Acc. Stainless steel + oct. nickel.

Data sheet

ManufacturerPA

Download

Racc. gir. diritto MF1/4

Download (323.66k)
