> >Adhesive heater resistance 15x8 cm 220V 12W double insulation 30 cm of cable
Adhesive heater resistance View larger

Adhesive heater resistance 15x8 cm 220V 12W double insulation 30 cm of cable

EL 15x8 220V

New product

XMAT heating elements are made by interposing a resistive circuit (resistance) between the layers of Polyester. Consequently, elements with thin and particularly flexible thicknesses suitable and suitable for heating any type of flat or curved surface are obtained. Possibility to integrate sensors or thermostats.

More details

25,00 € tax excl.

More info

Features:

  • Size 15x8 cm.
  • Power supply 220 V.
  • 12 W absorption
  • Max working temperature 110 ° C
  • Max temp. With 105 ° C adhesive
  • Peak temperature max. 130 ° C
  • Typical Thicknesses (μm) 250
  • Typical flat dimensions 3000 x 600
  • Bending radius approx. 8 mm
  • Maximum load 6 kg / cm2

Advantages:

  1. Flexibility and lightness.
  2. Fixings by direct adhesion, hooks, velcro, vulcanization.
  3. Temperature / power differentiation on the surface.
  4. Integration of sensors.

Download

Resistenza riscaldatore adesivo

Download (1.07M)
