NV10 banknote reader parallel version

Features
• Compact design without stack
• Improved detection technology
• Proven reliability in the field
• Future proof
• A compilation standard for global applications
• Simple maintenance, free firmware updates
• Over 100 different world currencies accepted

Technical specifications
Dimensions (LxHxP) 119 x 86 x 166 mm
Weight 550 g
Power supply 12 Vdc +/- 10% (MDB version: min 23 V - max 42 V)
Energy consumption 0.2 A Standby - 1A Running - 1.5A Peak
Operating temperature 0 ° C to 50 ° C - 5 to 95% humidity without condensation
Banknotes accepted up to 82 x 160 mm
Banknotes recognizable up to 15 denominations of different banknotes in ccTalk, serial, pulse and track validation mode, 4 banknotes in parallel mode
Acceptance speed 3 seconds
MCBF 200,000
