Ebara TP JE150 self-priming electric pump

GMTPJE150

New product

Self-priming electric pumps in AISI 304 stainless steel.
The electric pumps of the JES-JE series are electric pumps in AISI 304 stainless steel. These are self-priming pumps equipped with a Venturi group (ejector and diffuser), which are easy to use and light thanks to their small dimensions. Constructively they have the pump body, support and seal disc in AISI 304 steel.

More details

525,10 € tax excl.

More info

They are equipped with AISI 303 shaft (for the part in contact with the liquid). The impellers are different depending on the model: for the JES electric pumps the impeller is made of PPO + PS reinforced with glass fibers, while for the JE the impeller is made of AISI 304. For both versions the mechanical seal is in Ceramic / Carbon / NBR. The motors are 2 pole closed asynchronous, self-ventilated with internal ventilation. IE3 high energy efficiency starting from 0.75 Kw

FEATURES:

• Head from 11.5 to 49 m
• Flow rate from 0.3 to 4.5 m3 / h
• Maximum operating pressure 6 bar
• Maximum liquid temperature 45 ° C
• Maximum suction depth 8 m

Data sheet

ManufacturerEbara

Download

Elettropompa autoadescante

Download (140.63k)
