> >>2 ways 1/4 "solenoid valve body in brass
Solenoid valve body ODE View larger

2 ways 1/4 "solenoid valve body in brass

ODE2

New product

Direct acting solenoid valve suitable for interception of fluids compatible with construction materials.
Minimum operating pressure is not required.
The materials used and the tests performed guarantee reliability and durability

Functionality 2 Way Direct Drive, N.C.
Connections G 1/4
Material Brass
Flow rate Kv (l / min) 1.5, 2.1, 3.5, 5

More details

25,00 € tax excl.

More info

Applications Water, Air, Car Wash, Industrial Automation, Compressors, Combustible Gases, Industrial Washing, Coffee Machines, Water Treatment, Steam

Brass body - UNI EN 12165 CW617N
Brass built-in sleeve - UNI EN 12165 CW617N
Fixed core AISI 400 series stainless steel
Mobile core AISI 400 series stainless steel
Copper displacement ring - Cu 99.9%
AISI 300 series stainless steel spring
Standard Shutter: V = FKM
On request: B = NBR
Brass Orifice - UNI EN 12165 CW617N

Data sheet

ManufacturerOde

Download

Corpo elettrovalvola ODE

Download (99.75k)
