> >>Vertical multistage pump EL.POMPA SC409T
Multistage vertical pump View larger

Vertical multistage pump EL.POMPA SC409T

LOWEL.POMPA SC409T

New product

Highly reliable and technologically innovative multi-purpose pump capable of meeting the needs of a wide variety of users. Numerous construction types are available with nominal capacities of 1-3-5-10-15-22-33-46-66-92-125 m³ / h. All models ≥ 0.75kW are equipped with IE3 standard motors.

More details

884,40 € tax excl.

More info

Replaceable balanced mechanical seal without having to disassemble the pump (for 10-15-22SV> = 5.5kW, 33-46-66-92-125SV)

Floating system for the self alignment of the wear ring (PPS technopolymer reinforced with fiberglass able to withstand chemically corrosive, mechanically aggressive and high temperature liquids)

Specifications:

  • Flow rate: up to 160 m³ / h
  • Head: up to 330 m
  • Power supply: mono and tri-phase 50 and 60 Hz
  • Power: from 0.37 kW up to 55 kW
  • Maximum pressure: 40 bar
  • Liquid temperature from -30 ° C to 120 ° C (the version is available for high temperatures up to 180 ° C)

Data sheet

ManufacturerLowara

Download

Pompa verticale multistadio

Download (649.91k)
