> >>RCW 1520 Pump Right 15 liters 200 bar
Right hand RCW 1520 pump View larger

RCW 1520 Pump Right 15 liters 200 bar

AR RCW 1520

New product

Alternative 3-piston volumetric pumps for use on washing systems. Pump body and covers in die-cast aluminum (cast iron for the RTF series). Nickel-plated stamped brass head for better protection and resistance in medium aggressive atmospheres. Piston movement achieved through the rod-crank system.

More details

760,00 € tax excl.

More info

Connecting rods in special die-cast zinc-aluminum alloy with anti-friction or bronze properties (RCW and RTF series). Double seal sealing system able to minimize any water leaks. Molded and heat treated steel shaft to ensure high mechanical strength. High quality bench bearings compared to the required standards.

FEATURES

Right attack CWX pump
Flow rate 15 liters per minute
Max pressure 200 Bar
Max power 7.5 hp
Turns 1450 minutes
Weight 9.5 kg

Data sheet

ManufacturerAnnovi Reverberi

Download

Pompa RCW 1520 Destra

Download (168.57k)
