> >>Lowara BGM7 / A electric pump
Lowara electric pump View larger

Lowara BGM7 / A electric pump

LOW BGM7A

New product

Close-coupled centrifugal electric pumps with built-in ejector system, designed to maintain priming even in the presence of gases dissolved in water. The wide use of pressed stainless steel guarantees durability over time, considerable lightness and excellent yields. Suitable for use with edible water.

More details

440,00 € tax excl.

More info

Characteristic data:

  • Flow rate: up to 4.2 m3 / h
  • Head: up to 53 m
  • Power supply: three-phase and single-phase 50 and 60 Hz
  • Power: from 0.37 kW up to 1.1 kW
  • Maximum operating pressure: 8 bar
  • Maximum suction height: 8 m
  • Maximum ambient temperature: 40 ° C
  • Temperature of the pumped liquid: from -10 ° C to + 40 ° C
  • Class insulation: F
  • Protection: IP55

Materials:

  • Pump body: Stainless steel
  • Impeller: Stainless steel
  • Diffuser: Technopolymer
  • Ejector: Technopolymer
  • Sealing disc: Stainless steel
  • Mechanical seal: Ceramic / Carbon / EPDM
  • Loading and unloading caps: Nickel-plated brass
  • Elastomers: EPDM

Data sheet

ManufacturerLowara

Download

Elettropompa Lowara BGM7/A

Download (268k)
