> >>Pump CWX 1517 Right 15 liters 170 bar
Right CWX pump View larger

Pump CWX 1517 Right 15 liters 170 bar

AR CWX 1517

New product

Alternative 3-piston volumetric pumps for use on washing systems. Pump body and covers in die-cast aluminum (cast iron for the RTF series). Nickel-plated stamped brass head for better protection and resistance in medium aggressive atmospheres. Piston movement achieved through the rod-crank system.

More details

1 055,00 € tax excl.

More info

Connecting rods in special die-cast zinc-aluminum alloy with anti-friction or bronze properties (RCW and RTF series). Double seal sealing system able to minimize any water leaks. Molded and heat treated steel shaft to ensure high mechanical strength. High quality bench bearings compared to the required standards.

Right attack CWX pump
Flow rate 15 liters per minute
Max pressure 170 Bar
Max power 7.5 hp
Turns 950 minutes
Weight 16 kg

Data sheet

ManufacturerAnnovi Reverberi

Download

Pompa CWX Destra

Download (397.41k)
