> >>ODE 2-way solenoid valve body 1/4 "PLUS INOX
Solenoid valve body ODE 2 PLUS INOX View larger

ODE 2-way solenoid valve body 1/4 "PLUS INOX

ODE2PLUSINOX

New product

Direct acting solenoid valve suitable for interception of fluids compatible with construction materials. Minimum operating pressure is not required. The materials used and the tests performed guarantee reliability and durability

Functionality 2 Way Direct Drive, N.C., N.A.
Connections G 1/4
Material 316 Stainless Steel AISI
Flow rate Kv (l / min) 3,2, 4, 5, 9

More details

126,01 € tax excl.

More info

Applications Water, Air, Car Wash, Industrial Automation, Chemistry, Food & Beverage, Bottling, Coffee Machines, Medical, Packaging, Water Treatment, Steam, Vending

NSF Certification
Body AISI 316 stainless steel
AISI 300 series stainless steel tube
Fixed core AISI 400 series stainless steel
Mobile core AISI 400 series stainless steel
Phase-shift ring Golden copper
AISI 300 series stainless steel spring
Standard Shutter: V = FKM
On request: E = EPDM
Port AISI 316 stainless steel
On demand:
Pg 9 or Pg 11 connector
ISO 4400 connector compliance

Data sheet

ManufacturerOde

Download

Corpo elettrov. ODE 2 PLUS INOX

Download (101.37k)
